Premium Efficiency Motor IE3 Series

Model:

IE3 - TEFC

Applications:

Motor Ratings :
0.75kW ~ 200kW,2P ~ 6P
Three phase squirrel-cage induction motor
Continuous Duty
50/60Hz,200/220V
Low Voltage
Protection: IP54
Efficiency meet JIS C4034-30:2011 IE3






Interchangeability -  All motors are built in accordance with IEC international standard which are interchangeable with all IEC motors.


F Class Insulation- Safe and long lasting F class insulations are resistant to heat, humidity and chemicals.


Excellent Performance - Short starting and breaking time provides high efficiency for frequent start-stop operations are achieved by low inertia and high acceleration torque design.


Low Noise and Vibration - Constructions are perfectly designed and precision machined. Rotors are dynamically balanced to assure vibration free and quite operation.


Low maintenance – High quality pre-lubricated, double shielded ball bearings are used for frame 180 and below.
Lightweight and small size – Lightweight design is space saving and easy set-up.



Specifications refer to the download.
